Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Controller type | SIMATIC ET 200SP Open Controller, CPU 1515SP PC2 TF |
| RAM | 8 GB |
| Storage | 128 GB CFast |
| Operating system | Windows 10 IoT Enterprise LTSC 2019 64-bit |
| Preinstalled controller | S7-1500 Failsafe Software Controller CPU 1505SP TF V2x |
| PROFINET connection | 1x connection for ET 200SP BusAdapter PROFINET |
| Ethernet | 1x 10/100/1000 Mbps Ethernet |
| USB interfaces | 2x USB 3.0; 2x USB 2.0 |
| Display interface | 1x DisplayPort |
| Storage slots | 1x CFast; 1x SD/MMC |
Key Features
- Open Controller configuration: SIMATIC ET 200SP Open Controller with CPU 1515SP PC2 TF; basic device: 6ES7677-2DB40-0AA0.
- Memory and software: 8 GB RAM and 128 GB CFast with Windows 10 IoT Enterprise LTSC 2019 64-bit and S7-1500 Failsafe Software Controller CPU 1505SP TF V2x preinstalled.
- ET 200SP BusAdapter connection: 1x connection for an ET 200SP BusAdapter PROFINET.
- Ethernet interface: 1x 10/100/1000 Mbps Ethernet.
- USB and display interfaces: 2x USB 3.0, 2x USB 2.0, and 1x DisplayPort.
- Storage slots and documentation: 1x CFast slot and 1x SD/MMC slot; documentation and restore image are on CFast.
Frequently Asked Questions
1. What controller configuration does 6ES7677-2WB42-0GB0 have?
It is a SIMATIC ET 200SP Open Controller with CPU 1515SP PC2 TF; the basic device is 6ES7677-2DB40-0AA0.
2. Which interfaces are available on 6ES7677-2WB42-0GB0?
It has 1x connection for an ET 200SP BusAdapter PROFINET, 1x 10/100/1000 Mbps Ethernet, 2x USB 3.0, 2x USB 2.0, and 1x DisplayPort.
3. What memory and storage does this Open Controller have?
It has 8 GB RAM and a 128 GB CFast card. It also has 1x CFast slot and 1x SD/MMC slot.
