Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Controller type | SIMATIC ET 200SP Open Controller, CPU 1515SP PC2 T + HMI 128PT |
| RAM | 8 GB |
| Storage | 128 GB CFast with Windows 10 IoT Enterprise LTSC 2019 64-bit |
| PROFINET interface | 1x connection for ET 200SP BusAdapter PROFINET |
| Ethernet interface | 1x 10/100/1000 Mbps Ethernet |
| USB interfaces | 2x USB 3.0 and 2x USB 2.0 |
| Display interface | 1x DisplayPort |
Key Features
- Controller and HMI: SIMATIC ET 200SP Open Controller with CPU 1515SP PC2 T, HMI 128PT and 8 GB RAM.
- Preinstalled software: Includes S7-1500 Software Controller CPU 1505SP T V2x and WinCC Runtime Advanced V17 preinstalled.
- Storage and license: Has 128 GB CFast with Windows 10 IoT Enterprise LTSC 2019 64-bit and a 128 PowerTags license.
- Interfaces: Provides 1x slot CFast, 1x slot SD/MMC, 1x connection for ET 200SP BusAdapter PROFINET, 1x 10/100/1000 Mbps Ethernet, 2x USB 3.0, 2x USB 2.0 and 1x DisplayPort.
- Dimensions and weight: Packaging dimensions are 18.90 x 14.20 x 9.20 cm; net weight is 1.026 kg.
- Product lifecycle: Lifecycle status: Active Product.
Frequently Asked Questions
1. What controller and HMI are included in 6ES7677-2VB42-0GK0?
It has CPU 1515SP PC2 T, HMI 128PT and 8 GB RAM.
2. Which storage and software are supplied?
It has 128 GB CFast with Windows 10 IoT Enterprise LTSC 2019 64-bit, S7-1500 Software Controller CPU 1505SP T V2x and WinCC Runtime Advanced V17 preinstalled.
3. Which interfaces should be verified for this configuration?
Verify the CFast, SD/MMC, ET 200SP BusAdapter PROFINET, 10/100/1000 Mbps Ethernet, USB 3.0, USB 2.0 and DisplayPort interfaces.
