Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product type | CPU 1510SP F-1 PN |
| Program work memory | 300 kbyte |
| Data work memory | 1 Mbyte |
| PROFINET interface | 1; integrated 3-port switch |
| Bit-operation time, typ. | 6 ns |
| PROFIBUS interface | 1; via CM DP module |
| Rated supply voltage | 24 V DC |
| SIMATIC Memory Card | Required; 1 slot |
| Load memory, max. | 32 Gbyte; plug-in SIMATIC Memory Card |
Applications
- Fail-safe program execution: The CPU supports LAD and FBD programming including failsafe, plus STL, SCL, and GRAPH.
- PROFINET communication: The CPU supports PROFINET IO Controller, PROFINET IO Device, IRT, direct data exchange, and up to 128 connectable IO Devices.
- Motion Control: The CPU supports Motion Control technology objects with 1 120 available Motion Control resources.
Key Features
- Fail-safe CPU for ET 200SP: CPU 1510SP F-1 PN with FS04 hardware functional status and 300 kbyte integrated work memory for the program.
- PROFINET IRT interface: 1 PROFINET interface with an integrated 3-port switch, PROFINET IO Controller and IO Device support, and 6 ns typical bit-operation time.
- Memory and supply: 1 Mbyte integrated work memory for data, plug-in SIMATIC Memory Card load memory up to 32 Gbyte, and 24 V DC rated supply voltage.
- Communication interfaces: PROFINET and PROFIBUS DP communication are supported; PROFIBUS is available via a CM DP module, and RS 485 transmission reaches 12 Mbit/s.
- Diagnostics and security: The CPU has a diagnostic buffer with up to 1 000 entries, RUN/STOP, ERROR, MAINT, and PWR LEDs, Secure Boot, and signed firmware update support.
Frequently Asked Questions
1. What is the function of Siemens 6ES7510-1SK03-0AB0?
It is a CPU 1510SP F-1 PN for ET 200SP with 300 kbyte program work memory, 1 Mbyte data work memory, and fail-safe LAD and FBD support.
2. Which PROFINET capabilities does this CPU have?
It has 1 PROFINET interface with an integrated 3-port switch and supports PROFINET IO Controller, PROFINET IO Device, IRT, and direct data exchange.
3. What memory does the CPU require or support?
A SIMATIC Memory Card is required. The plug-in load memory supports up to 32 Gbyte, and the CPU has 1 slot for the card.
4. Which supply voltage does the CPU use?
The rated supply voltage is 24 V DC, with a permissible range from 19.2 V DC to 28.8 V DC and reverse polarity protection.
5. What must be verified before requesting a quote?
Verify that the configuration includes the required SIMATIC Memory Card and BusAdapter for port 1 and port 2.
