Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Module type | SIMATIC DP CPU 1514SP TF-2 PN for ET 200SP |
| Program work memory | 900 KB |
| Data work memory | 3.5 MB |
| 1st interface | PROFINET IRT with 2-port switch |
| 2nd interface | PROFINET RT with 6 ns bit performance |
| Included server module | 6ES7193-6PA00-0AA0 |
| Required components | SIMATIC Memory Card; BusAdapter for 1st interface |
Key Features
- Central processing unit: SIMATIC DP CPU 1514SP TF-2 PN for ET 200SP.
- Memory capacity: Has 900 KB work memory for programs and 3.5 MB for data.
- PROFINET interfaces: The 1st interface is PROFINET IRT with a 2-port switch; the 2nd interface is PROFINET RT with 6 ns bit performance.
- Required and included components: Includes server module 6ES7193-6PA00-0AA0. A SIMATIC Memory Card and a BusAdapter for the 1st interface are required.
Frequently Asked Questions
1. What is the function of Siemens 6ES7514-2WN03-0AB0?
It is a SIMATIC DP CPU 1514SP TF-2 PN central processing unit for ET 200SP.
2. What memory does the CPU have?
It has 900 KB work memory for programs and 3.5 MB for data.
3. Which PROFINET interfaces are provided?
The 1st interface provides PROFINET IRT with a 2-port switch, and the 2nd provides PROFINET RT with 6 ns bit performance.
4. Which components are required or included?
A SIMATIC Memory Card is required, and a BusAdapter is required for the 1st interface. Server module 6ES7193-6PA00-0AA0 is included.
