Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product type | CPU 1510SP-1 PN |
| Rated supply voltage | 24 V DC |
| PROFINET interface | 1; PROFINET IRT with integrated 3-port switch |
| Typical bit-operation time | 72 ns |
| SIMATIC Memory Card required | Yes; 1 slot |
| BusAdapter required | Yes; for port 1 and 2 |
| Maximum PROFINET IO Devices | 64 |
| PROFIBUS DP master | Yes; via CM DP module |
| Maximum operating temperature | 60 °C; horizontal installation |
Applications
- PROFINET I/O control: The CPU supports PROFINET IO Controller and PROFINET IO Device functions.
- OPC UA data access: The CPU supports OPC UA Server data access for read, write, and subscribe operations, plus method calls.
- Motion control: The CPU supports Motion Control technology objects and provides 800 Motion Control resources.
Key Features
- CPU for ET 200SP: CPU 1510SP-1 PN is a central processing unit for ET 200SP.
- PROFINET interface: The CPU has 1 PROFINET interface with PROFINET IRT and an integrated 3-port switch.
- Supply voltage: Rated supply voltage is 24 V DC, with a permissible range of 19.2 V DC to 28.8 V DC and reverse polarity protection.
- Processing performance: Typical processing times are 72 ns for bit operations, 86 ns for word operations, 115 ns for fixed point arithmetic, and 461 ns for floating point arithmetic.
- Memory card and BusAdapter: A SIMATIC Memory Card and BusAdapter are required; 1 memory-card slot is provided.
- Diagnostics and replacement: The CPU has I&M0 to I&M3 data, diagnostic buffer with up to 1 000 entries, and multi-hot swapping.
Frequently Asked Questions
1. What is the function of Siemens 6ES7510-1DJ01-0AB0?
It is a SIMATIC DP CPU 1510SP-1 PN central processing unit for ET 200SP.
2. How many PROFINET ports does the CPU have?
It has 3 ports: 1 integrated port and 2 via BusAdapter.
3. What supply voltage does this CPU require?
The rated supply voltage is 24 V DC, with a permissible range of 19.2 V DC to 28.8 V DC.
4. Is a memory card included with the configuration?
The CPU requires a SIMATIC Memory Card; the source does not state that the card is included.
5. What is required for ports 1 and 2?
A BusAdapter is required for port 1 and 2.
