Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Module type | AQ 4xU/I ST analog output module |
| Analog outputs | 4; > +60 °C maximum 4x ±10 V permissible |
| Output ranges | 0 to 10 V; 1 V to 5 V; -10 V to +10 V; 0 to 20 mA; -20 mA to +20 mA; 4 mA to 20 mA |
| Resolution | Maximum 16 bit with overrange, including sign |
| Cycle time | Minimum 3.2 ms for all channels, independent of the number of activated channels |
| Supply voltage | 24 V DC rated; 19.2 V to 28.8 V permissible |
| Diagnostics | Diagnostics, diagnostic alarm, substitute values, and supply-voltage monitoring |
Applications
- Actuator signal output: Provides voltage or current output connections for actuators.
Key Features
- Analog output channels: 4 analog outputs in groups of 4; above +60 °C, maximum 4x ±10 V is permissible.
- Output ranges: Voltage: 0 to 10 V, 1 V to 5 V, and -10 V to +10 V. Current: 0 to 20 mA, -20 mA to +20 mA, and 4 mA to 20 mA.
- Resolution and timing: Resolution with overrange: maximum 16 bit. Conversion time per channel: 0.5 ms; cycle time for all channels: minimum 3.2 ms.
- Diagnostics: Diagnostics, diagnostic alarm, substitute values, supply-voltage monitoring, wire-break detection for current output, and short-circuit detection for voltage output.
- Supply and isolation: Rated supply: 24 V DC; permissible range: 19.2 V to 28.8 V. Isolation is provided between channels and the backplane bus, and between channels and load voltage L+.
- Connection and mounting: Voltage outputs support two-wire and four-wire connections; current outputs support two-wire connections. The module is rail-based and includes a shielding bracket and shield terminal.
Frequently Asked Questions
1. How many analog outputs does Siemens 6AG2532-5HD00-4AB0 have?
It has 4 analog outputs in groups of 4.
2. Which signal ranges does the module support?
It supports voltage ranges of 0 to 10 V, 1 V to 5 V, and -10 V to +10 V, plus current ranges of 0 to 20 mA, -20 mA to +20 mA, and 4 mA to 20 mA.
3. What resolution and cycle time does it provide?
Resolution with overrange is maximum 16 bit, and the cycle time for all channels is minimum 3.2 ms.
4. What supply voltage does the module require?
The rated supply is 24 V DC, with a permissible range of 19.2 V to 28.8 V.
5. Which connections and diagnostics are included?
Voltage outputs support two-wire and four-wire connections; current outputs support two-wire connections. Diagnostics include wire-break detection for current output and short-circuit detection for voltage output.
