Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Module type | SM 1222, DQ 16×24 V DC/0.5 A |
| Digital outputs | 16 |
| Output voltage, rated | 24 V DC |
| Output current, rated | 0.5 A |
| Supply voltage, permissible range | 20.4 V to 28.8 V DC |
| Output delay, 0 to 1, max. | 50 μs with resistive load |
| Output delay, 1 to 0, max. | 200 μs with resistive load |
| Backplane bus current, max. | 140 mA at 5 V DC |
| Operating ambient temperature | -40 °C to 70 °C; start-up at -25 °C |
| Required connection | Front connector |
Applications
- Digital output control: Controls digital output signals through 16 transistor DQ channels at 24 V DC.
Key Features
- Digital outputs: 16 transistor digital outputs, arranged in groups of 1.
- Output rating: 24 V DC rated output voltage and 0.5 A rated output current.
- Output switching capacity: Maximum 0.5 A with resistive load and maximum 5 W on lamp load.
- Diagnostics: Diagnostic alarm and LED indication for output status.
- Electrical isolation: Digital outputs are separated from the backplane bus by 500 V AC, with channel groups of 1.
- Installation and protection: Required front connector, IP20 protection, and dimensions of 45 mm × 100 mm × 75 mm.
Frequently Asked Questions
1. How many digital outputs does 6AG1222-1BH32-2XB0 have?
It has 16 transistor digital outputs, arranged in groups of 1.
2. What are the output voltage and current ratings?
The rated output voltage is 24 V DC and the rated output current is 0.5 A.
3. What connection is required for this module?
A front connector is required.
