Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product type | IPC227E Box PC, built-in unit |
| Supply voltage | 24 V DC |
| Processor | Intel Celeron N2930 |
| Main memory | 8 GB |
| Storage | 480 GB SSD |
| Industrial Ethernet | 2x Ethernet (RJ45), 100 Mbps and 1000 Mbps |
| USB ports | 1x USB 3.0 / 3x USB 2.0 |
| Video interface | 1x DisplayPort |
| Mounting | DIN rail, wall mounting, portrait mounting |
| Exclusion | Without SIMATIC software |
Key Features
- Box PC design: IPC227E Box PC, built-in unit for DIN rail, wall, or portrait mounting.
- Processor and memory: Intel Celeron N2930 processor with 8 GB RAM; DDR3L SO-DIMM memory, maximum 8 Gbyte.
- Storage: 480 GB SSD and 1 CFast slot.
- Ethernet interfaces: 2 Ethernet RJ45 interfaces with 100 Mbps and 1000 Mbps support.
- Ports and display: 1x USB 3.0, 3x USB 2.0, and 1x DisplayPort.
- Monitoring and protection: Temperature monitoring and watchdog are available; IP degree of protection is IP40.
Frequently Asked Questions
1. What processor and memory does Siemens 6ES7647-8BB34-7DA1 have?
It has an Intel Celeron N2930 processor and 8 GB RAM.
2. Which Ethernet and USB interfaces are included?
It has 2x Ethernet (RJ45) with 100 Mbps and 1000 Mbps support, plus 1x USB 3.0 and 3x USB 2.0.
3. How can the IPC227E Box PC be mounted?
It supports DIN rail, wall, and portrait mounting.
4. Is SIMATIC software included?
It is without SIMATIC software.
