Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product type | IOT2050 |
| Design | IoT Gateway, built-in unit |
| Supply voltage | 12/24 V DC |
| Digital inputs | 20 |
| Input voltage range | 0 … 5 V |
| PROFINET interfaces | 2 |
| Serial interface | 1x COM (1x RS 232 / 422 / 485) |
| Ethernet interfaces | 2x Gbit Ethernet RJ45 |
| Memory | 2 GB RAM, DDR4 |
| Storage | 16 GB eMMC; 1x microSD card slot |
| Video interface | 1x DisplayPort |
| Protection | IP20 |
Key Features
- IOT2050 IoT Gateway: Product type designation: IOT2050. Design: IoT Gateway, built-in unit.
- Digital inputs: The unit has 20 digital inputs with DC input voltage and a 0 … 5 V input range.
- Communication interfaces: It has 2 PROFINET interfaces, 2x Gbit Ethernet RJ45, and 1x COM supporting RS 232 / 422 / 485.
- Memory and storage: The unit has 2 GB RAM, DDR4 memory, 16 GB eMMC, and 1x microSD card slot.
- Video and USB connections: Connections include 1x DisplayPort and 2x USB2.0.
- Supply and protection: Supply voltage: 12/24 V DC. IP degree of protection: IP20. LED status display and temperature monitoring are available.
Frequently Asked Questions
1. What is the product type of Siemens 6ES7647-0BB00-1YA2?
It is an IOT2050 IoT Gateway designed as a built-in unit.
2. How many digital inputs does the IOT2050 have?
It has 20 digital inputs with a 0 … 5 V input range.
3. Which communication interfaces are available?
It has 2 PROFINET interfaces, 2x Gbit Ethernet RJ45, and 1x COM (1x RS 232 / 422 / 485).
4. What supply voltage does it use?
The supply voltage is 12/24 V DC.
