Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product type | Extension Unit 15" PROFIsafe |
| Mounting positions | 8 |
| Supply voltage | 24 V DC; permissible range 19.2 V to 28.8 V |
| PROFINET interfaces | 2; including switch |
| PROFIsafe | 1x SIL 2 (two-channel) or 2x SIL 3 (single-channel) emergency stop sensor |
| Protection | IP65 all-round |
| Current consumption | 150 mA; without load |
| Active power input | 3 W; additionally 0.1 W per control element with LED |
Applications
- Control element installation: Install up to 8 control elements in the available mounting positions.
- Emergency stop sensing: Connect emergency stop sensors through PROFIsafe: 1x SIL 2 (two-channel) or 2x SIL 3 (single-channel).
- HMI / IPC PRO mounting: Mount the unit on the lower part of a 16:9 HMI / IPC PRO device using a screwed joint.
Key Features
- Control element positions: 8 mounting positions are available, and 8 control elements can be installed.
- Parameterizable keys: The unit has parameterizable keys.
- PROFINET interfaces: 2 PROFINET interfaces are provided, including a switch.
- PROFIsafe function: PROFIsafe supports 1x SIL 2 (two-channel) or 2x SIL 3 (single-channel) emergency stop sensor.
- DC supply: Rated supply is 24 V DC, with a permissible range of 19.2 V to 28.8 V.
- Mounting and protection: The unit uses a screwed joint for mounting on the lower part of a 16:9 HMI / IPC PRO device and has IP65 all-round protection.
Frequently Asked Questions
1. How many control elements can be installed?
Up to 8 control elements can be installed in 8 mounting positions.
2. What supply voltage does the 6AV7674-1LA43-0AA0 use?
It uses 24 V DC, with a permissible range of 19.2 V to 28.8 V.
3. What PROFIsafe emergency stop configurations are supported?
It supports 1x SIL 2 (two-channel) or 2x SIL 3 (single-channel) emergency stop sensor.
4. How is the unit mounted?
It is mounted on the lower part of a 16:9 HMI / IPC PRO device using a screwed joint.
