Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product type | MTP1900 Unified Comfort |
| Display | 18.5 in TFT widescreen, 1 920 × 1 080 pixel |
| Touch operation | Touch screen and multi-touch screen |
| Industrial Ethernet interfaces | 2; 2 switch ports plus independent port |
| Serial interface | 1 combined RS 422 / 485 interface |
| USB interfaces | 4; USB 3.1 Gen. 1 type A |
| PROFINET | Yes; PROFINET IO protocol: No |
| Supply voltage | 24 V DC rated; 19.2 V to 28.8 V permissible range |
| Current consumption | 1.2 A rated; 1.7 A maximum |
| Front protection | IP69 |
| Rear protection | IP20 |
Key Features
- 18.5" widescreen display: The TFT display has an 18.5 in screen diagonal, 1 920 pixel horizontal resolution, 1 080 pixel vertical resolution, and 16 777 216 colors.
- Touch operation: The panel has touch-screen and multi-touch-screen operation, with numeric and alphanumeric Onscreen keyboard support.
- Industrial Ethernet and PROFINET: It has 2 industrial Ethernet interfaces with 2 ports on an integrated switch plus an independent port. PROFINET, TCP/IP, DHCP, SNMP, DCP, and LLDP are supported; PROFINET IO protocol is not supported.
- USB and serial interfaces: The panel has 4 USB 3.1 Gen. 1 type A interfaces and 1 combined RS 422 / 485 interface.
- 24 V DC supply: The rated supply voltage is 24 V DC, with a permissible range from 19.2 V to 28.8 V. Rated current consumption is 1.2 A and maximum current consumption is 1.7 A.
- Hygienic stainless-steel design: The panel has a hygienic stainless-steel design, blue FDA-compliant gasket, IP69 protection at the front, and IP20 protection at the rear.
Frequently Asked Questions
1. Which display does the Siemens 6AV2128-3UB40-0AX0 have?
It has an 18.5 in TFT widescreen display with 1 920 pixel horizontal resolution, 1 080 pixel vertical resolution, and 16 777 216 colors.
2. How many Ethernet and serial interfaces does the panel have?
It has 2 industrial Ethernet interfaces with 2 switch ports plus an independent port, and 1 combined RS 422 / 485 interface.
3. Which protocols are supported?
PROFINET, TCP/IP, DHCP, SNMP, DCP, and LLDP are supported. The PROFINET IO protocol is not supported.
4. What supply voltage and current are required?
The rated supply is 24 V DC, with a permissible range from 19.2 V to 28.8 V. Rated current consumption is 1.2 A and maximum current consumption is 1.7 A.
5. What protection does the panel provide?
It has IP69 protection at the front and IP20 protection at the rear.
