Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product lifecycle | Active Product |
| Input supply | 3 AC, 380 … 480 V +10 % -20 %, 47 … 63 Hz |
| Rated power (LO) | 11.00 kW | 15.00 hp |
| Rated power (HO) | 7.50 kW | 10.00 hp |
| Communication | PROFIBUS DP |
| Digital inputs | 6 standard digital inputs; 1 fail-safe digital input |
| Analog I/O | 1 differential analog input, 10 bit; 1 non-isolated analog output |
| Output frequency | 0 … 240 Hz for vector control; 0 … 550 Hz for V/f control |
| Frame size | FSC |
Applications
- Drive control: Supports V/f linear, square-law, and parameterizable control; V/f with flux current control (FCC); V/f ECO linear and square-law control; and sensorless vector control.
Key Features
- Rated power: Rated power: 11.00 kW | 15.00 hp (LO); 7.50 kW | 10.00 hp (HO).
- PROFIBUS DP communication: Communication: PROFIBUS DP.
- I/O interface: I/O interface: 6 digital inputs, 2 digital outputs, 1 analog input, 1 analog output, and 1 fail-safe digital input.
- Frequency control: Output frequency: 0 … 240 Hz for vector control and 0 … 550 Hz for V/f control.
- Connections and protection: Plug-in screw terminals are provided on the line side, motor end, and DC link. Degree of protection: IP20 / UL open type.
Frequently Asked Questions
1. What communication interface does the Siemens 6SL3210-1KE22-6AP1 have?
It has PROFIBUS DP communication.
2. How many I/O points does this SINAMICS G120C converter provide?
It has 6 standard digital inputs, 1 fail-safe digital input, 2 digital outputs, 1 differential analog input, and 1 non-isolated analog output.
3. What are the rated power values for the 6SL3210-1KE22-6AP1?
Rated power is 11.00 kW | 15.00 hp for LO and 7.50 kW | 10.00 hp for HO.
4. Which connections and protection details should be verified before quotation?
Verify the plug-in screw terminals on the line side, motor end, and DC link, plus the IP20 / UL open type degree of protection.
