Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Output voltage | 24 V DC |
| Rated output current | 10 A |
| Supplied active power, typical | 240 W |
| AC supply voltage settings | 120 … 230 V; 230 … 500 V |
| Input voltage ranges | 85 … 264 V; 176 … 550 V |
| Output voltage adjustment | 24 … 28.8 V via potentiometer |
| Input and output isolation | Galvanic isolation |
| Protection class | IP20 |
Applications
- DC power conversion: Provides a stabilized, isolated 24 V DC output from a 1-phase or 2-phase AC supply.
Key Features
- 24 V/10 A DC output: Rated output is 24 V DC and 10 A, with typical supplied active power of 240 W.
- Wide-range AC input: The 1-phase and 2-phase AC power supply has 120 … 230 V and 230 … 500 V supply-voltage settings, with input ranges of 85 … 264 V and 176 … 550 V.
- Adjustable output voltage: The output voltage is adjustable via potentiometer from 24 … 28.8 V.
- Conformal coating and temperature range: The SIPLUS power supply has conformal coating and a -25…+70 °C temperature range.
- Protection and monitoring: The output is short-circuit proof, with selectable constant current characteristic approx. 12 A or latching shutdown, plus green and yellow/red LED indications.
- Galvanic isolation and IP20: Input and output have galvanic isolation. The protection class is IP20.
Frequently Asked Questions
1. What output does the Siemens 6AG1334-3BA10-7AA0 provide?
It provides 24 V DC at a rated output current of 10 A, with typical supplied active power of 240 W.
2. What AC input ranges does this power supply support?
The supply-voltage settings are 120 … 230 V and 230 … 500 V AC. The corresponding input voltage ranges are 85 … 264 V and 176 … 550 V.
3. Is the output voltage adjustable?
Yes. A potentiometer adjusts the output from 24 … 28.8 V.
4. How is short-circuit protection implemented?
The output is short-circuit proof and uses either a constant current characteristic approx. 12 A or latching shutdown.
