Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product type | CPU 1515TF-2 PN |
| Program work memory | 1.5 Mbyte |
| Data work memory | 4.5 Mbyte |
| PROFINET interfaces | 2 |
| 1st interface | PROFINET IRT; RJ 45 X1; 2-port integrated switch |
| 2nd interface | PROFINET RT; RJ 45 X2; 1 port |
| Bit performance | 6 ns |
| Rated supply | 24 V DC |
Applications
- Motion Control: Supports Motion Control technology objects, with 2 400 available Motion Control resources.
- PROFINET communication: Supports PROFINET IO Controller, PROFINET IO Device, PROFINET IRT, PROFINET RT, and SIMATIC communication.
- Process control: Supports PID_Compact, PID_3Step, and PID-Temp controllers with integrated optimization.
Key Features
- CPU processing performance: Bit operations: 6 ns typ.; word operations: 7 ns typ.; fixed point arithmetic: 9 ns typ.; floating point arithmetic: 37 ns typ.
- PROFINET interfaces: 2 interfaces: 1st interface with PROFINET IRT, 2-port integrated switch and RJ 45 X1; 2nd interface with PROFINET RT and RJ 45 X2.
- Work memory: 1.5 Mbyte integrated work memory for the program and 4.5 Mbyte integrated work memory for data.
- Supply and memory card: Rated supply: 24 V DC; permissible range: 19.2 V to 28.8 V DC. 1 SIMATIC Memory Card is required; plug-in load memory is up to 32 Gbyte.
Frequently Asked Questions
1. What is the function of the Siemens 6ES7515-2UN03-0AB0?
It is a SIMATIC S7-1500T CPU 1515TF-2 PN with Motion Control technology objects and PROFINET communication functions.
2. How many PROFINET interfaces does this CPU have?
It has 2 PROFINET interfaces. The 1st interface supports PROFINET IRT with a 2-port integrated switch, and the 2nd supports PROFINET RT.
3. What supply voltage does the CPU require?
The rated supply is 24 V DC, with a permissible range of 19.2 V to 28.8 V DC.
4. Is a memory card included in the CPU configuration?
A SIMATIC Memory Card is required. The source does not state that it is included.
