Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product type | SIMATIC S7-1200 Battery Board |
| Function | Long-term real-time clock buffering |
| Installation | Plug-in in the signal board receptacle of the S7-12XX |
| Firmware requirement | FW3.0 or higher |
| Battery | CR1025 not included in scope of delivery |
| Diagnostics indication | PLC MAINT LED signals battery replacement need |
| Protection | IP20 |
| Product lifecycle | Active Product |
Applications
- Real-time clock buffering: Provides long-term buffering for the real-time clock.
Key Features
- Battery board function: Provides long-term buffering for the real-time clock.
- S7-12XX installation: Plug-in installation in the signal board receptacle of the S7-12XX.
- Firmware requirement: For S7-12XX systems with FW3.0 or higher.
- Battery scope: CR1025 battery is not included in the scope of delivery.
- Maintenance indication: The PLC MAINT LED signals that the battery needs to be replaced.
- Protection and diagnostics: Has IP20 protection, alarms, and a diagnostics function.
Frequently Asked Questions
1. What is the function of the 6ES7297-0AX30-0XA0?
It provides long-term buffering for the real-time clock.
2. How is the Battery Board installed?
It is plugged into the signal board receptacle of the S7-12XX.
3. What firmware is required?
The S7-12XX requires FW3.0 or higher.
4. Is the CR1025 battery included?
No. The CR1025 battery is not included in the scope of delivery.
