Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product type | SIM 274 |
| Digital inputs | 24; input switches |
| Digital outputs | 0 |
| Analog inputs | 0 |
| Analog outputs | 0 |
| Supported CPUs | CPU 215/216/226 |
Applications
- Digital input simulation: Simulates 24 DC digital input states through input switches.
Key Features
- Simulator module: Product type designation: SIM 274 for the SIMATIC S7-200 family.
- Digital input switches: 24 digital inputs with input switches.
- No output channels: Digital outputs: 0; analog inputs: 0; analog outputs: 0.
- Compact dimensions: Dimensions: 148.3 mm wide, 35.5 mm high, and 22 mm deep.
- Approximate weight: Weight: approximately 60 g.
- Product status: The product is identified as a spare part and is in the start of its final year of support.
Frequently Asked Questions
1. What is the function of the Siemens 6ES7274-1XK00-0XA0?
It is a SIM274 simulator module with 24 DC input switches.
2. How many input and output channels does the module have?
It has 24 digital inputs, 0 digital outputs, 0 analog inputs, and 0 analog outputs.
3. What are the dimensions and weight of the module?
Its dimensions are 148.3 mm wide, 35.5 mm high, and 22 mm deep; weight is approximately 60 g.
4. What should be verified before requesting a quote?
Verify the exact order number, the CPU 215/216/226 designation, and the required spare-part configuration.
