Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Module type | SIMATIC DP bus module |
| System context | ET 200M |
| I/O module capacity | Two 40 mm wide I/O modules |
| Product lifecycle | Product cancellation |
Applications
- I/O module removal and insertion: Used for holding I/O modules for removal and insertion function.
Key Features
- SIMATIC DP bus module: Bus module for ET 200M.
- I/O module capacity: Holds two 40 mm wide I/O modules.
- Removal and insertion function: Supports removal and insertion of the held I/O modules.
- Installed width: Width: 97 mm; 80 mm when installed.
- Dimensions and weight: Height: 92 mm; depth: 30 mm; weight, approx.: 140 g.
- Product lifecycle: Product cancellation.
Frequently Asked Questions
1. What is the function of 6ES7195-7HB00-0XA0?
It is a SIMATIC DP bus module for ET 200M that holds two 40 mm wide I/O modules for removal and insertion.
2. How many I/O modules does the bus module hold?
It holds two 40 mm wide I/O modules.
3. What are the dimensions of 6ES7195-7HB00-0XA0?
Width: 97 mm; 80 mm when installed. Height: 92 mm. Depth: 30 mm.
4. What is the approximate weight?
Weight, approx.: 140 g.
5. What should be checked before requesting a quote?
Check the exact order number, ET 200M context, two-module capacity, 40 mm module width, and removal and insertion function.
