Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product type | Strain relief for PROFINET |
| Supply quantity | 5 units |
| Operating temperature | 0 °C to 60 °C |
| Minimum dew point | -60 °C; suitable for dry room applications |
Key Features
- Product type: Strain relief for PROFINET.
- Supply quantity: SIMATIC cable grip for SIMATIC BusAdapter, 5 units.
- Dimensions: Width: 15.5 mm; height: 51.4 mm; depth: 45 mm.
- Cable tie dimensions: Recommended cable tie width: 2.5 mm; maximum width: 7 mm; minimum length: 60 mm.
- Operating temperature: 0 °C to 60 °C.
- Humidity condition: Minimum dew point: -60 °C; suitable for dry room applications.
Frequently Asked Questions
1. What is the function of the 6ES7193-6RA00-1AN0?
It is a strain relief for PROFINET and a SIMATIC cable grip for SIMATIC BusAdapter.
2. How many cable grips are supplied?
The configuration contains 5 units.
3. What are the dimensions of the cable grip?
The width is 15.5 mm, the height is 51.4 mm, and the depth is 45 mm.
4. What cable tie sizes are specified?
The recommended cable tie width is 2.5 mm, the maximum width is 7 mm, and the minimum length is 60 mm.
