Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Module type | SM500 |
| Analog inputs | 8 |
| Analog outputs | 8 |
| Digital inputs | 16 |
| Digital outputs | 16 |
| Incremental encoder inputs | 4 |
| Absolute value encoder inputs | 4 |
| Analog resolution | Max. 12 bit with overrange, including sign |
| Typical power loss | 12.5 W |
| Digital input current | 3 mA typical for signal "1" |
| Digital output current | 50 mA rated value for signal "1" |
Key Features
- Module type: SM500 signal module.
- I/O channels: 8 analog inputs, 8 analog outputs, 16 digital inputs, and 16 digital outputs.
- Encoder inputs: 4 incremental encoder inputs and 4 absolute value encoder inputs.
- Analog resolution: Resolution with overrange, including sign: max. 12 bit.
- Power loss: Typical power loss: 12.5 W.
- Dimensions: Width: 20 mm; height: 233 mm; depth: 160 mm.
Frequently Asked Questions
1. What I/O does the Siemens 6DD1640-0AH0 SM500 have?
It has 8 analog inputs, 8 analog outputs, 16 digital inputs, and 16 digital outputs.
2. How many encoder inputs does the SM500 have?
It has 4 incremental encoder inputs and 4 absolute value encoder inputs.
3. What analog resolution does this module provide?
The resolution with overrange, including sign, is max. 12 bit.
4. What are the dimensions of the SM500?
The dimensions are 20 mm wide, 233 mm high, and 160 mm deep.
