Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Display type | TFT widescreen display, LED backlighting |
| Screen diagonal | 21.5 in; 22" |
| Multi-touch | Yes; Projective-capacitive |
| Image resolution | 1 920 x 1 080 pixels |
| Video interface | DisplayPort V1.2 |
| USB interfaces | 2; USB 2.0 Type A |
| Supply | 24 V DC; PELV / SELV floating |
| Supply range | 19.2 V to 28.8 V |
| Mounting | Support arm mounting; stand mounting |
| Protection | IP65 at the front and rear |
Key Features
- 22-inch multi-touch display: TFT widescreen display with LED backlighting, 21.5 in; 22" screen diagonal, and projective-capacitive multi-touch.
- Full HD resolution: Image resolution: 1 920 x 1 080 pixels, with 0.248 mm horizontal and vertical pixel size.
- DisplayPort and USB interfaces: DisplayPort V1.2 and 2 USB 2.0 Type A interfaces are provided; USB interfaces are located on the rear.
- 24 V DC supply: Rated supply: 24 V DC; permissible range: 19.2 V to 28.8 V.
- Support arm mounting: Support arm mounting and stand mounting are supported; front mounting is not supported.
- Front and rear IP65 protection: Protection rating is IP65 at the front and rear; the front has Enclosure Type 4 and Enclosure Type 4x.
Frequently Asked Questions
1. What display resolution does the 6AV7863-4MA15-2AA0 have?
It has an image resolution of 1 920 x 1 080 pixels.
2. Does this model have multi-touch operation?
Yes. It has a projective-capacitive multi-touch screen.
3. Which video and USB interfaces are available?
It has DisplayPort V1.2 and 2 USB 2.0 Type A interfaces. The USB interfaces are on the rear.
4. What supply voltage does the display require?
The rated supply is 24 V DC, with a permissible range from 19.2 V to 28.8 V.
5. Which mounting options are supported?
Support arm mounting and stand mounting are supported. Front mounting is not supported.
