Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product type | CFast memory card |
| Memory type | CFast Type I |
| Flash design | SLC NAND flash |
| Memory size | 8 Gbyte; 1 year (data retention) |
| Write speed | up to 60 MB/s (UDMA6) |
| Read speed | up to 100 MB/s (UDMA6) |
| Rated DC supply | 3.3 V; ±5 % |
| Active power input | 0.7 W |
| Inactive power input | 0.3 W |
| Supported slot | IPCs with corresponding slot |
Key Features
- Memory type: CFast Type I memory card with SLC NAND flash design.
- Memory size: 8 Gbyte; 1 year data retention.
- Data speeds: Write speed: up to 60 MB/s (UDMA6); read speed: up to 100 MB/s (UDMA6).
- Supply voltage: DC supply; rated value: 3.3 V; ±5 %.
- Power input: Active power input: 0.7 W; inactive: 0.3 W.
- Supply scope: 1 CFast 8 GB is included.
Frequently Asked Questions
1. What type of memory card is Siemens 6ES7648-2BF10-0XH0?
It is a CFast Type I memory card with an SLC NAND flash design.
2. What memory capacity does 6ES7648-2BF10-0XH0 provide?
The memory size is 8 Gbyte, with 1 year data retention.
3. What are the write and read speeds?
Write speed is up to 60 MB/s (UDMA6), and read speed is up to 100 MB/s (UDMA6).
4. What supply voltage does this CFast memory card use?
The supply is DC, with a rated value of 3.3 V; ±5 %.
5. What is included in the supply scope?
The supply scope includes 1 CFast 8 GB.
