Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product type | CFast memory card |
| Memory size | 2 Gbyte; 1 year (data retention) |
| Memory type | CFast Type I |
| Flash design | SLC NAND flash |
| Write speed | up to 60 MB/s (UDMA6) |
| Read speed | up to 100 MB/s (UDMA6) |
| Supply voltage | DC; 3.3 V; ±5 % |
| Active power input | typ. 0.7 W |
| Inactive power input | 0.3 W |
| Installation context | For IPCs with corresponding slot |
| Scope of supply | 1 CFast 2 GB |
Key Features
- CFast memory card: Product type: CFast memory card for IPCs with a corresponding slot.
- Memory capacity: Memory size: 2 Gbyte; data retention: 1 year.
- CFast Type I and SLC NAND flash: Memory type: CFast Type I. Design: SLC NAND flash.
- Read and write speed: Write speed: up to 60 MB/s (UDMA6); read speed: up to 100 MB/s (UDMA6).
- Electrical data: Supply voltage: DC, rated value 3.3 V; ±5 %. Active power input: typ. 0.7 W; inactive 0.3 W.
- Scope of supply and lifecycle: Scope of supply: 1 CFast 2 GB. Product lifecycle: Announcement of product phase-out.
Frequently Asked Questions
1. What is the 6ES7648-2BF10-0XF0?
It is a SIMATIC CFast memory card with 2 Gbyte capacity and CFast Type I design for IPCs with a corresponding slot.
2. What memory technology does this CFast card use?
It uses SLC NAND flash and has a memory size of 2 Gbyte with 1 year of data retention.
3. What are the read and write speeds?
The write speed is up to 60 MB/s (UDMA6), and the read speed is up to 100 MB/s (UDMA6).
4. What supply voltage and power input does it require?
The supply is DC at a rated value of 3.3 V; ±5 %. Active power input is typ. 0.7 W, and inactive power input is 0.3 W.
5. What is included in the configuration?
The scope of supply is 1 CFast 2 GB card. The product lifecycle is Announcement of product phase-out.
