Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product type | CFast memory card |
| Memory size | 4 Gbyte; 1 year (data retention) |
| Memory type | CFast Type I |
| Storage design | SLC NAND flash |
| Write speed | up to 60 MB/s (UDMA6) |
| Read speed | up to 100 MB/s (UDMA6) |
| Rated supply value | 3.3 V DC; ±5 % |
| Active power input | 0.7 W typical; inactive 0.3 W |
| Scope of supply | 1 CFast 4 GB |
Key Features
- CFast memory card: Product type: CFast memory card for IPCs with a corresponding slot.
- 4 Gbyte storage: Memory size: 4 Gbyte; data retention: 1 year.
- SLC NAND flash: Storage design: SLC NAND flash; memory type: CFast Type I.
- Write and read speed: Write speed: up to 60 MB/s (UDMA6); read speed: up to 100 MB/s (UDMA6).
- DC supply: Rated supply value: 3.3 V DC; ±5 %.
- Active power input: Active power input: 0.7 W typical; inactive: 0.3 W.
Frequently Asked Questions
1. What is the Siemens 6ES7648-2BF10-0XG0?
It is a SIMATIC CFast memory card with 4 Gbyte capacity and SLC NAND flash.
2. What memory type and storage size does it have?
It has CFast Type I memory and 4 Gbyte storage, with 1 year of data retention.
3. What are its write and read speeds?
Write speed is up to 60 MB/s (UDMA6), and read speed is up to 100 MB/s (UDMA6).
4. What supply voltage does it use?
It uses 3.3 V DC with a rated tolerance of ±5 %.
