Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Keyboard type | USB keyboard, international US |
| Keyboard assignment | 86 keys, International QWERTY, US version |
| Function keys | 12 |
| Touchpad | Capacitive touchpad with cursor control and left and right mouse button |
| USB interface | 1 × USB 2.0 type A |
| Rated supply voltage | 5 V DC |
| USB supply range | 4.35 V to 5.25 V |
| Rated current consumption | 55 mA, including touchpad and LED |
| Mounting | Desktop, PRO support arm, drawer |
| Protection | IP65 all-round; USB plug IP67 with screws when fully inserted |
Key Features
- Stainless steel USB keyboard: USB keyboard with stainless steel buttons, black laser-inscribed key lettering and long-stroke keys with 2 mm contact travel.
- International US layout: Keyboard assignment: 86 keys with an international QWERTY, US version layout; integrated number pad and 12 function keys.
- Capacitive touchpad: Capacitive touchpad provides cursor control with left and right mouse buttons; no scroll wheel is included.
- USB 2.0 connection: One USB 2.0 type A interface is provided. The USB plug enclosure is IP67.
- Supply and current: Rated supply voltage: 5 V DC; permissible USB range: 4.35 V to 5.25 V. Rated current consumption is 55 mA, including the touchpad and LED.
- Mounting and protection: Mounting options are desktop, PRO support arm and drawer. The keyboard has IP65 all-round protection; the USB plug meets IP67 with screws when fully inserted.
Frequently Asked Questions
1. What is the keyboard layout of Siemens 6AV6881-0AU14-1DB0?
It has 86 keys with an international QWERTY, US version layout, an integrated number pad and 12 function keys.
2. Which interface and supply does the keyboard use?
It has 1 USB 2.0 type A interface and a rated supply voltage of 5 V DC; the USB range is 4.35 V to 5.25 V.
3. Does the keyboard include a touchpad?
Yes. It has a capacitive touchpad with cursor control and left and right mouse buttons, without a scroll wheel.
4. How can the keyboard be mounted?
It can be mounted on a desktop, PRO support arm or drawer.
