Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Memory capacity | 32 Gbyte |
| Read transmission rate | 600 Mbit/s maximum, typical |
| Write transmission rate | 600 Mbit/s maximum, typical |
| Device-side pin count | 9 |
| Rated supply voltage | 3.3 V DC |
| Maximum supply voltage | 3.6 V DC |
| Current consumption | 100 mA rated value; typical, maximum value |
| Memory type | Secure Digital memory card |
| Mounting position | Any, dependent on target device |
| Insertion cycles | Typically 10 000 |
| Lifecycle | Active Product |
Key Features
- Memory capacity: 32 Gbyte Secure Digital memory card.
- Read and write transmission rate: 600 Mbit/s maximum, typical, for reading and writing.
- Device-side interface: 9 device-side pins.
- Supply voltage: 3.3 V rated DC value; 3.6 V maximum.
- Current consumption: 100 mA rated value; typical, maximum value.
- Installation and protection features: Any mounting position dependent on the target device; portrait and landscape mounting are possible. Wear leveling and a write protection switch are included; write protection effectiveness depends on the device.
Frequently Asked Questions
1. What is the memory capacity of the Siemens 6AV6881-0AP40-0AA0?
It has a 32 Gbyte Secure Digital memory capacity.
2. What are the read and write transmission rates?
The maximum transmission rate is 600 Mbit/s for reading and 600 Mbit/s for writing; both values are typical.
3. What supply does the memory card use?
It uses DC supply with a rated value of 3.3 V and a maximum of 3.6 V.
4. How is the memory card mounted?
The mounting position can be any position, dependent on the target device; portrait and landscape mounting are possible.
5. What is included in the configuration?
The scope of supply is 1 memory card.
