Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product type | MM memory card |
| Memory size | 128 Mbyte |
| Memory type | MultiMediaCard |
| Rated supply voltage | 3.3 V DC |
| Maximum supply voltage | 3.6 V DC |
| Current consumption | 80 mA; Typical, maximum value |
| Device-side pins | 7 |
| Write endurance per cell | > 100 000 write/read cycles |
| Write endurance per card | > 3 000 000 write/read cycles |
| Mounting position | Any, dependent on target device |
| Insertion cycles | Typically 10 000 |
Key Features
- Memory capacity: Memory size: 128 Mbyte. Type of memory: MultiMediaCard.
- DC supply: Supply voltage: DC; rated value: 3.3 V; maximum: 3.6 V.
- Current consumption: Current consumption: 80 mA; typical, maximum value.
- Device-side interface: Number of pins device-side: 7.
- Write endurance: Wear leveling is available: > 100 000 write/read cycles per cell and > 3 000 000 write/read cycles per card.
- Mounting and format: Mounting position is any, dependent on the target device. Portrait and landscape mounting are possible.
Frequently Asked Questions
1. What is the product type of Siemens 6AV6671-1CB00-0AX2?
It is an MM memory card with MultiMediaCard memory type.
2. What memory capacity does the 6AV6671-1CB00-0AX2 have?
It has 128 Mbyte memory capacity.
3. What supply voltage and current consumption does it use?
Supply is DC at 3.3 V rated and 3.6 V maximum. Current consumption is 80 mA, typical maximum value.
4. How many device-side pins does the memory card have?
It has 7 device-side pins.
