Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product type | IFP1500 V2 |
| Display | 15.6 in TFT widescreen, LED backlighting |
| Touch operation | Projective-capacitive multi-touch |
| Image resolution | 1 920 x 1 080 |
| Supply | 24 V DC; 19.2 V to 28.8 V permissible range |
| Current consumption | 1 A rated; 1.3 A maximum |
| Video interface | DisplayPort V1.2 |
| USB | 2x onboard USB on the rear; keyboard/mouse connection |
| Installation | Built-in unit; front mounting |
| Mounting orientation | Portrait and landscape |
| Front protection | IP65 |
Key Features
- Multi-touch widescreen display: TFT widescreen display with LED backlighting, 15.6 in screen diagonal, projective-capacitive multi-touch operation, and 16 777 216 colors (24 bit).
- Image resolution and brightness: Image resolution: 1 920 x 1 080; luminance: 400 cd/m2; brightness/contrast: 400 cd/m2 / 700:1.
- DC supply: Rated supply: 24 V DC; permissible range: 19.2 V to 28.8 V. Current consumption is 1 A rated and 1.3 A maximum.
- Display and USB interfaces: DisplayPort V1.2 and Ethernet monitor support; 2x onboard USB connections on the rear and USB connection for keyboard/mouse.
- Built-in installation: Built-in unit with front mounting. Portrait and landscape mounting are possible; VESA mounting is not supported.
- Front protection: Front protection: IP65. The front has Enclosure Type 4, Enclosure Type 4x, and Enclosure Type 12.
Frequently Asked Questions
1. What display does the 6AV7863-5MA20-2AA0 use?
It has a 15.6 in TFT widescreen LED display with projective-capacitive multi-touch operation and 1 920 x 1 080 image resolution.
2. What supply voltage and current does this display require?
The rated supply is 24 V DC, with a permissible range of 19.2 V to 28.8 V. Current consumption is 1 A rated and 1.3 A maximum.
3. Which interfaces are included?
It has DisplayPort V1.2, Ethernet monitor support, 2x onboard USB connections on the rear, and a USB connection for keyboard/mouse.
4. Can it be mounted in portrait format or with VESA?
Portrait and landscape mounting are possible, with front mounting for the built-in unit. VESA mounting is not supported.
