Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Display type | TFT widescreen display, LED backlighting |
| Screen diagonal | 22 in |
| Touch operation | Projective-capacitive multi-touch |
| Resolution | 1 920 x 1 080 pixel |
| Industrial Ethernet | 1; Ethernet, 1 port, RJ45 |
| Video interface | DisplayPort V1.1 |
| Supply voltage | 24 V DC; PELV / SELV floating |
| Power loss | 40 W typ.; 65 W max. |
| Protection | IP65 at the front and rear |
| Mounting | Support arm mounting; VESA mounting with VESA adapter set |
| Product lifecycle | Product cancellation |
Applications
- Ethernet monitoring: The display functions as an Ethernet monitor.
- Touchscreen operation: The projective-capacitive touch screen supports multi-touch operation.
Key Features
- 22" multi-touch display: TFT widescreen display with LED backlighting, projective-capacitive touch operation, and 16 777 216 colors (24 bit).
- Full HD resolution: Horizontal image resolution: 1 920 pixel; vertical image resolution: 1 080 pixel.
- Ethernet monitor interface: 1 industrial Ethernet interface with Ethernet, 1 port, RJ45; the display is an Ethernet monitor.
- 24 V DC supply: Rated value: 24 V; permissible range: 19.2 V to 28.8 V; PELV / SELV floating.
- IP65 protection: IP65 at the front and rear; fully enclosed, with Enclosure Type 4 and Enclosure Type 4x at the front.
- Support arm and VESA mounting: Support arm mounting is suitable for support arm and extension components; VESA mounting is available with a VESA adapter set.
Frequently Asked Questions
1. What display resolution does the Siemens 6AV7466-8MA02-0AA0 have?
It has a horizontal image resolution of 1 920 pixel and a vertical image resolution of 1 080 pixel.
2. Which interfaces are available on this display?
It has 1 industrial Ethernet interface with 1 port and RJ45, DisplayPort V1.1, and USB interfaces, including 2x onboard USB on the rear.
3. How can the display be mounted?
It has support arm mounting and is suitable for support arm and extension components. VESA mounting is available with a VESA adapter set; front mounting and stand mounting are not available.
