Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product type | ITC2200 V3 industrial thin client |
| Display | TFT widescreen display with LED backlighting |
| Screen diagonal | 21.5 in; 22" |
| Touch operation | Projective-capacitive multi-touch screen |
| Image resolution | 1 920 x 1 080 |
| Industrial Ethernet interfaces | 2; 2 ports (switch) |
| Protocols | RDP, VNC viewer, Sm@rtServer, TCP/IP, DHCP, SNMP, DCP, LLDP |
| Supply voltage | 24 V DC; permissible range 19.2 V to 28.8 V |
Key Features
- 22" widescreen TFT display: The display has a 21.5 in; 22" screen diagonal, LED backlighting and 1 920 x 1 080 image resolution.
- Capacitive multi-touch: The unit has a projective-capacitive multi-touch screen and a monitor keyboard.
- Industrial Ethernet interfaces: It has 2 industrial Ethernet interfaces with 2 ports (switch) and a maximum transmission rate of 1 000 Mbit/s.
- Communication protocols: Supported protocols and services include RDP, VNC viewer, Sm@rtServer, TCP/IP, DHCP, SNMP, DCP, LLDP, HTTP, HTML5, XML, CSS and JavaScript.
- DC supply and connections: Supply: 24 V DC, with a permissible range of 19.2 V to 28.8 V. The unit has 4 USB interfaces on the rear, including 2x onboard.
- Built-in front mounting: The unit is a built-in unit with front mounting. Support arm mounting and stand mounting are not supported; front protection is IP65.
Frequently Asked Questions
1. What display does the Siemens 6AV6646-1BA22-1NA0 have?
It has a 21.5 in; 22" TFT widescreen display with LED backlighting, 1 920 x 1 080 image resolution and a projective-capacitive multi-touch screen.
2. How many industrial Ethernet and USB interfaces are included?
It has 2 industrial Ethernet interfaces with 2 ports (switch), plus 4 USB interfaces on the rear, including 2x onboard.
3. Which communication protocols are supported?
Supported protocols and services include RDP, VNC viewer, Sm@rtServer, TCP/IP, DHCP, SNMP, DCP, LLDP, HTTP, HTML5, XML, CSS and JavaScript.
4. How is this unit mounted and protected?
It is a built-in unit for front mounting. Support arm mounting and stand mounting are not supported, and front protection is IP65.
