Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product type | ITC1500 V3 industrial thin client |
| Display | 15.6 in TFT widescreen display with LED backlighting |
| Touch operation | Projective-capacitive multi-touch screen |
| Image resolution | 1 366 x 768 |
| Industrial Ethernet | 2 ports (switch), maximum 1 000 Mbit/s |
| Terminal link protocols | Sm@rtServer, RDP, VNC viewer |
| Supply voltage | 24 V DC; permissible range 19.2 V to 28.8 V |
| Mounting | Built-in unit with front mounting |
Key Features
- 15.6 in multi-touch display: TFT widescreen display with LED backlighting, 1 366 x 768 resolution, 16 777 216 colors, and projective-capacitive multi-touch operation.
- Industrial Ethernet interfaces: 2 industrial Ethernet interfaces with 2 ports (switch) and a maximum transmission rate of 1 000 Mbit/s.
- Terminal link protocols: Supports Sm@rtServer, RDP, and VNC viewer; Citrix and SINUMERIK are not supported.
- USB connectivity: 4 USB interfaces are provided on the rear, including 2x onboard USB; the keyboard/mouse connection is USB.
- DC supply: Rated supply voltage is 24 V DC, with a permissible range from 19.2 V to 28.8 V; rated current consumption is 1.4 A.
- Built-in front mounting: Built-in unit with front mounting; support arm mounting and stand mounting are not supported. Maximum permitted tilt is 35° forward or backward from vertical.
Frequently Asked Questions
1. What display does the Siemens 6AV6646-1BA15-0NA0 have?
It has a 15.6 in TFT widescreen display with LED backlighting, 1 366 x 768 resolution, and projective-capacitive multi-touch operation.
2. Which interfaces and terminal link protocols are supported?
It has 2 industrial Ethernet ports (switch) and 4 rear USB interfaces. Supported terminal link protocols include Sm@rtServer, RDP, and VNC viewer.
3. What supply voltage does the ITC1500 V3 require?
The rated supply voltage is 24 V DC, with a permissible range from 19.2 V to 28.8 V.
4. What mounting configuration should be verified before inquiry?
The unit supports built-in front mounting. Support arm mounting and stand mounting are not supported; the maximum permitted forward or backward tilt is 35° from vertical.
