Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product type | MP277 8" Touch |
| Display | 7.5 in TFT color display, 65 536 colors |
| Touch screen | Analog, resistive |
| Resolution | 640 pixel × 480 pixel |
| User data memory | 6 Mbyte |
| Interfaces | 1x Ethernet (RJ45), 1x RS 422, 1x RS 485, 2 USB |
| Protocols | PROFINET IO, PROFIBUS, TCP/IP, MODBUS |
| Mounting | Vertical; maximum permissible angle of inclination without external ventilation: 35° |
| Protection | IP65 at the front; IP20 at the rear |
Key Features
- Display and touch operation: 7.5 in TFT color display with 65 536 colors, 640 pixel × 480 pixel resolution, and analog resistive touch screen.
- Interfaces: 1x Ethernet (RJ45), 1x RS 422, 1x RS 485, and 2 USB interfaces.
- Protocols: Supports PROFINET IO, PROFIBUS, TCP/IP, and MODBUS.
- Memory and clock: 6 Mbyte memory for user data; hardware clock with battery backup, retentive and synchronizable.
- Mounting and protection: Vertical mounting; maximum permissible angle of inclination without external ventilation is 35°. Protection is IP65 at the front and IP20 at the rear.
- Product status: Product cancellation. The new part is blocked for delivery as of 01.01.2015; the spare part can continue to be purchased as required, with a price that may deviate from the new part.
Frequently Asked Questions
1. What display and touch screen does the Siemens 6AV6643-0CB01-1AX1 have?
It has a 7.5 in TFT color display with 65 536 colors, 640 pixel × 480 pixel resolution, and analog resistive touch operation.
2. Which interfaces are available on the Siemens 6AV6643-0CB01-1AX1?
It has 1x Ethernet (RJ45), 1x RS 422, 1x RS 485, and 2 USB interfaces.
3. Which protocols does the Siemens 6AV6643-0CB01-1AX1 support?
It supports PROFINET IO, PROFIBUS, TCP/IP, and MODBUS.
4. How is the Siemens 6AV6643-0CB01-1AX1 mounted and protected?
It is mounted vertically. The maximum permissible angle of inclination without external ventilation is 35°; protection is IP65 at the front and IP20 at the rear.
