Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Rated power | 0.55 kW |
| Overload | 150% for 3 s |
| Supply | 380-480 V 3AC +10/-20%, 47-63 Hz |
| I/O interface | 6 DI, 2 DQ, 1 AI, 1 AQ |
| Integrated fieldbus | CANopen |
| Safety function | Safe Torque Off integrated |
| Filter | Class A integrated |
| Degree of protection | IP20/UL Open Type |
| External supply | 24 V |
Key Features
- Rated power and overload: Rated power: 0.55 kW; overload: 150% for 3 s.
- I/O interface: I/O interface: 6 DI, 2 DQ, 1 AI and 1 AQ.
- Communication and safety: Integrated fieldbus: CANopen. Safe Torque Off is integrated.
- Electrical supply: Supply: 380-480 V 3AC +10/-20%, 47-63 Hz. External 24 V is provided.
- Filter and protection: Integrated filter: class A. Degree of protection: IP20/UL Open Type.
- Product lifecycle and packaging: Product lifecycle: Start of final year of support. Packaging dimensions: 225.00 x 270.00 x 85.00 mm; net weight: 2.300 kg.
Frequently Asked Questions
1. What is the rated power and overload of 6SL3210-1KE11-8AC1?
Rated power is 0.55 kW, with 150% overload for 3 s.
2. Which I/O channels does 6SL3210-1KE11-8AC1 provide?
It provides 6 DI, 2 DQ, 1 AI and 1 AQ.
3. Which fieldbus and safety function are integrated?
The integrated fieldbus is CANopen, and Safe Torque Off is integrated.
4. What supply does this drive use?
Supply is 380-480 V 3AC +10/-20% at 47-63 Hz, with external 24 V.
