Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Communication | PROFIBUS DP |
| Standard digital inputs | 6 |
| Fail-safe digital inputs | 3 (Use of 6 × DI Standard) |
| Relay changer outputs | 2 |
| Differential analog/digital inputs | 2 |
| Non-isolated analog outputs | 2 |
| Operating voltage via Power Module | DC 24 V |
| External power supply | DC 20 … 29 V |
| Maximum power consumption | 0.50 A |
| Interfaces | USB and SD/MMC |
| Degree of protection | IP20 / UL open type |
Key Features
- PROFIBUS DP communication: Communication interface: PROFIBUS DP.
- Digital inputs and outputs: 6 standard digital inputs, 3 fail-safe digital inputs using 6 × DI Standard, and 2 relay changer outputs.
- Analog input and output: 2 differential analog/digital inputs and 2 non-isolated analog outputs.
- Safety Integrated functions: Safety Integrated STO, F-type SS1, SLS, SSM and SDI are included.
- Power supply: Operating voltage via the Power Module: DC 24 V. External power supply: DC 20 … 29 V; maximum power consumption: 0.50 A.
- Interfaces and protection: USB and SD/MMC interfaces; degree of protection IP20 / UL open type.
Frequently Asked Questions
1. Which communication interface does 6SL3244-0BB13-1PA1 have?
It has a PROFIBUS DP communication interface.
2. How many digital and analog channels does the control unit have?
It has 6 standard digital inputs, 3 fail-safe digital inputs using 6 × DI Standard, 2 relay changer outputs, 2 differential analog/digital inputs and 2 non-isolated analog outputs.
3. What power supplies are supported?
Operating voltage via the Power Module is DC 24 V. The external power supply range is DC 20 … 29 V.
4. Which interfaces are included?
The control unit has USB and SD/MMC interfaces.
