Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Communication | PROFIBUS DP |
| Standard digital inputs | 6 |
| Fail-safe digital inputs | 1 (Use of 2 × DI Standard) |
| Relay outputs | 2 |
| Analog / digital inputs | 2 (Differential input) |
| Analog outputs | 2 (Non-isolated output) |
| Operating voltage via Power Module | DC 24 V |
| Degree of protection | IP20 / UL open type |
Applications
- Drive control: Supports V/f, sensorless vector and encoderless torque control techniques for drive control.
Key Features
- PROFIBUS DP communication: Communication interface: PROFIBUS DP.
- Digital and analog I/O: The unit has 6 standard digital inputs, 1 fail-safe digital input using 2 standard digital inputs, 3 relay outputs, 2 differential analog inputs, and 2 non-isolated analog outputs.
- Control techniques: Supported techniques include V/f linear, square-law and parameterizable; V/f with flux current control (FCC); V/f ECO linear and square-law; sensorless vector control; and encoderless torque control.
- Interfaces and protection: The unit has USB and SD/MMC interfaces and degree of protection IP20 / UL open type.
- Power and installation data: Operating voltage via the Power Module is DC 24 V. External power supply: DC 20 … 29 V. Signal cable conductor cross-section: 0.05 … 1.50 mm2 (AWG 28 … AWG 16).
- Configuration exclusion: The unit is supplied without a power module and panel.
Frequently Asked Questions
1. What communication interface does the 6SL3244-0BB12-1PA1 have?
It has a PROFIBUS DP communication interface.
2. How many input and output channels does this control unit have?
It has 6 standard digital inputs, 1 fail-safe digital input using 2 standard digital inputs, 3 relay outputs, 2 differential analog inputs, and 2 non-isolated analog outputs.
3. Which control techniques are supported?
It supports V/f linear, square-law and parameterizable; V/f with flux current control (FCC); V/f ECO linear and square-law; sensorless vector control; and encoderless torque control.
4. What is included in this configuration?
It is without a power module and panel.
