Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Module type | SIPLUS DP diagnostic repeater |
| Based on | 6ES7972-0AB01-0XA0 |
| Rated supply voltage | 24 V DC |
| Permissible supply voltage | 20.4 V to 28.8 V DC |
| PROFIBUS transmission rate | 9.6 kbit/s to 12 Mbit/s; maximum 12 Mbit/s |
| Supply connection | Terminal module |
| PROFIBUS cable connection | FastConnect insulation displacement; 10 clamping cycles possible |
| IP degree of protection | IP20 |
| Operating ambient temperature | 0 °C to 60 °C |
Key Features
- Diagnostic repeater: SIPLUS DP diagnostic repeater based on 6ES7972-0AB01-0XA0 with conformal coating.
- PROFIBUS transmission rate: Maximum transmission rate: 12 Mbit/s; range: 9.6 kbit/s to 12 Mbit/s.
- Supply voltage: Rated supply voltage: 24 V DC; permissible range: 20.4 V to 28.8 V DC.
- Connection method: Supply voltage uses a terminal module; PROFIBUS cables use FastConnect insulation displacement with 10 clamping cycles possible.
- Protection and environmental conditions: IP20 protection; ambient temperature during operation: 0 °C to 60 °C, with Tmin including condensation/frost.
- Dimensions and weight: Width: 80 mm; height: 125 mm; depth: 67.5 mm; weight: approximately 300 g.
Frequently Asked Questions
1. What supply voltage does the Siemens 6AG1972-0AB01-4XA0 use?
It has a rated supply voltage of 24 V DC and a permissible range of 20.4 V to 28.8 V DC.
2. What PROFIBUS transmission rate does this diagnostic repeater support?
It supports 9.6 kbit/s to 12 Mbit/s, with a maximum transmission rate of 12 Mbit/s.
3. How are the supply voltage and PROFIBUS cables connected?
The supply voltage uses a terminal module. PROFIBUS cables use FastConnect insulation displacement, with 10 clamping cycles possible.
4. What are the dimensions and protection rating?
The dimensions are 80 mm x 125 mm x 67.5 mm, and the protection rating is IP20.
