Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product type | SIPLUS NET OLM/P11 optical link module |
| Interfaces | 1 RS-485; 1 plastic FOC interface with 2 BFOC sockets |
| Connections | Signaling contact; test port |
| Operating temperature | -25…+60 °C during operation in horizontal mounting position |
| Storage and transport temperature | -40…+70 °C |
| Installation altitude | Maximum 5000 m |
| Coating | Conformal coating, class A; class 2 for high availability |
| Relative humidity | 100 % maximum, including condensation and frost; horizontal installation |
| Lifecycle | Product cancellation |
Applications
- Optical link communication: Provides optical link communication through 1 RS-485 and 1 plastic FOC interface.
Key Features
- Optical link interfaces: Has 1 RS-485 interface and 1 plastic FOC interface with 2 BFOC sockets.
- Signaling and test connections: Includes a signaling contact and test port.
- Conformal coating: Has conformal coating, class A, with class 2 coating for high availability.
- Operating temperature: -25…+60 °C during operation in horizontal mounting position.
- Environmental protection: Relative humidity up to 100 %, including condensation and frost; no commissioning when condensation is present, with horizontal installation.
- Product lifecycle: Product cancellation.
Frequently Asked Questions
1. What interfaces does 6AG1503-2CA01-2AA0 have?
It has 1 RS-485 interface and 1 plastic FOC interface with 2 BFOC sockets.
2. Does the module include signaling and test connections?
Yes. It includes a signaling contact and test port.
3. What is the operating temperature?
The operating temperature is -25…+60 °C during operation in horizontal mounting position.
4. What coating does the module have?
It has conformal coating, class A, and coating class 2 for high availability.
5. What should be verified before requesting a quote?
Verify the exact order number, interfaces, horizontal mounting requirement, temperature conditions, and product lifecycle.
