Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product type | Connection plug |
| Connector | M8 plug connector, 4-pin, shielded |
| Protection | IP65/67 |
| Housing material | metal |
| Cable outlet | 180° cable outlet |
| Assembly temperature | -30 °C to 80 °C |
Applications
- ET-CONNECTION node connection: Connects ET-CONNECTION nodes, e.g. SIMATIC ET 200AL, in degree of protection IP65/67.
Key Features
- Connection plug: M8 plug connector for ET connection, with 4 pins and shielding.
- ET-CONNECTION node connection: Suitable for connecting ET-CONNECTION nodes, e.g. SIMATIC ET 200AL, in IP65/67 protection.
- Protection: IP degree of protection: IP65/67.
- Metal housing: The housing is made of metal.
- Cable outlet: The outgoing feeder has a 180° cable outlet.
- Assembly temperature: Ambient temperature during assembly: -30 °C to 80 °C.
Frequently Asked Questions
1. What is the function of Siemens 6ES7194-2AB00-0AA0?
It is an M8 connection plug for ET-CONNECTION nodes, such as SIMATIC ET 200AL.
2. How many pins does the M8 connector have?
The connector has 4 pins and is shielded.
3. What protection rating does this connector have?
It has IP65/67 protection.
4. What housing and cable outlet does it use?
It has a metal housing and a 180° cable outlet.
