Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product type | IPC277E |
| Display | 15" TFT touch |
| Display resolution | 1 280 × 800 pixel |
| Ethernet interfaces | 2x Ethernet (RJ45), 10/100/1000 Mbps |
| Serial interface | 1x COM; RS 232 / 422 / 485, selectable in the BIOS |
| Video interface | 1x DisplayPort |
| USB interfaces | 1x USB 3.0; 3x USB 2.0 |
| Supply voltage | 24 V DC |
| Processor | Intel Celeron N2930 (4C/4T) |
| Main memory | 4 GB RAM |
| Storage | 480 GB SSD; 1 CFast slot |
| Mounting and protection | Panel PC, built-in unit; IP65 front, IP20 rear |
Key Features
- 15" touch display: Analog resistive touch TFT with 1 280 × 800 pixel resolution.
- Ethernet interfaces: 2x 10/100/1000 Mbps Ethernet RJ45 interfaces; 100 Mbps and 1000 Mbps operation is supported.
- USB and video ports: 1x DisplayPort, 1x USB 3.0 and 3x USB 2.0.
- Serial interface: 1x COM interface supporting RS 232 / 422 / 485, selectable in the BIOS.
- Panel mounting and protection: Panel PC built-in unit with central design; portrait mounting is possible. Protection is IP65 at the front and IP20 at the rear.
- Selected computing configuration: Intel Celeron N2930 (4C/4T), 4 GB RAM, 480 GB SSD and 1 CFast slot. The configuration is without operating system and without SIMATIC software.
Frequently Asked Questions
1. What display does the 6AV7882-0DB20-0DA0 have?
It has a 15" analog resistive touch TFT with 1 280 × 800 pixel resolution.
2. Which interfaces are available on this IPC277E configuration?
It has 2x Ethernet RJ45, 1x DisplayPort, 1x USB 3.0, 3x USB 2.0 and 1x COM supporting RS 232 / 422 / 485, selectable in the BIOS.
3. How is the Panel PC mounted and protected?
It is a panel-mounted built-in unit with central design; portrait mounting is possible. The front has IP65 protection and the rear has IP20 protection.
4. What computing configuration is supplied?
This configuration has an Intel Celeron N2930 (4C/4T), 4 GB RAM and a 480 GB SSD. It is without operating system and without SIMATIC software.
