Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product type | Charging station for Mobile Panel 277(F) IWLAN |
| Supply voltage | 24 V DC |
| Permissible supply voltage range | 19.2 V to 28.8 V DC |
| Current consumption, rated value | 3.2 A |
| Active power input, typical | 77 W |
| Additional battery charging capacity | 2 additional batteries |
| Protection degree | IP65 |
| Product lifecycle | Product cancellation |
Applications
- Mobile Panel charging: Charges Mobile Panel 277(F) IWLAN.
- Additional battery charging: Charges 2 additional batteries.
- Mobile Panel storage: Stores Mobile Panel 277(F) IWLAN with a lock.
Key Features
- Mobile Panel charging and storage: Charges and stores Mobile Panel 277(F) IWLAN.
- Lock: Has a lock for the charging and storage station.
- Battery capacity: Charges 2 additional batteries.
- Supply voltage: Rated supply voltage: 24 V DC; permissible range: 19.2 V to 28.8 V.
- Power and current: Current consumption, rated value: 3.2 A. Active power input, typical: 77 W.
- Protection: IP degree of protection: IP65.
Frequently Asked Questions
1. What is Siemens 6AV6671-5CE00-0AX1 used for?
It charges and stores Mobile Panel 277(F) IWLAN and charges 2 additional batteries.
2. What supply voltage does the charging station require?
The rated supply voltage is 24 V DC, with a permissible range of 19.2 V to 28.8 V DC.
3. Does the charging station have a lock?
Yes. It has a lock for charging and storing Mobile Panel 277(F) IWLAN.
4. What protection degree does it have?
The IP degree of protection is IP65.
