Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Module type | SINAMICS S120 PM340 Power Module converter |
| Input | 380-480 V 3AC, 50/60 Hz |
| Output | 3 AC 60 A (30 kW) |
| Construction | Blocksize |
| Frame size | FSD |
| Cooling | Internal air cooling |
| Lifecycle | Product cancellation |
Applications
- Power conversion: Converts 380-480 V 3AC input to 3 AC output at 60 A (30 kW).
Key Features
- Converter power module: SINAMICS S120 PM340 Power Module converter.
- Input supply: 380-480 V 3AC, 50/60 Hz.
- Output: 3 AC 60 A (30 kW).
- Construction and cooling: Blocksize frame size FSD with internal air cooling.
- Net weight: 15.900 kg.
- Lifecycle: Product cancellation.
Frequently Asked Questions
1. What is the function of 6SL3210-1SE26-0UA0?
It is a SINAMICS S120 PM340 Power Module converter.
2. What are the input and output ratings?
Input is 380-480 V 3AC at 50/60 Hz; output is 3 AC 60 A (30 kW).
3. How is this power module constructed and cooled?
It has blocksize construction, frame size FSD, and internal air cooling.
