Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Input | 600 V DC |
| Output | 400 V 3 AC |
| Current | 9 A/9 A |
| Type of construction | booksize, external air cooling |
| Interface or cable | DRIVE-CLiQ cable |
| Product lifecycle | Product cancellation |
Key Features
- Double Motor Module: SINAMICS S120 Double Motor Module supplied as a spare part.
- Input and output: Input: 600 V DC. Output: 400 V 3 AC.
- Current rating: Current: 9 A/9 A.
- Cooling: Type of construction: booksize with external air cooling.
- Pulse patterns and safety functions: Has optimized pulse patterns and supports the extended Safety Integrated functions.
- Connection: Includes a DRIVE-CLiQ cable.
Frequently Asked Questions
1. What is the function of Siemens 6SL3121-2TE21-0AA4?
It is a SINAMICS S120 Double Motor Module and spare part.
2. What are the input, output, and current values?
The input is 600 V DC, the output is 400 V 3 AC, and the current is 9 A/9 A.
3. What cooling and connection details should be verified?
The type of construction is booksize with external air cooling, and the module includes a DRIVE-CLiQ cable.
