Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Module type | SINAMICS S120 Single Motor Module |
| Input | 600 V DC |
| Output voltage | 400 V 3 AC |
| Output current | 200 A at 8 kHz/140 A |
| Cooling | External air cooling |
| Interface | DRIVE-CLiQ cable |
Applications
- Single-motor power conversion: Provides 600 V DC input and 400 V 3 AC output for a SINAMICS S120 single-motor module configuration.
Key Features
- Single Motor Module: SINAMICS S120 component identified as a spare part for single-motor applications.
- Electrical ratings: Input: 600 V DC. Output: 400 V 3 AC.
- Output current: Output: 200 A at 8 kHz/140 A.
- Cooling and pulse patterns: External air cooling with optimized pulse patterns.
- Safety and interface: Supports the extended Safety Integrated functions and includes a DRIVE-CLiQ cable.
- Lifecycle: Product cancellation.
Frequently Asked Questions
1. What is the function of 6SL3121-1TE32-0AA4?
It is a SINAMICS S120 Single Motor Module spare part with 600 V DC input and 400 V 3 AC output.
2. What output current does this module provide?
The output is 200 A at 8 kHz/140 A.
3. What cooling and interface details should be checked?
The module has external air cooling, optimized pulse patterns, and includes a DRIVE-CLiQ cable.
4. What is the lifecycle status of this configuration?
Product cancellation.
