Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Module type | SINAMICS G120 Power Module PM 240-2 |
| Supply | 380-480 V 3 AC +10/-20%, 47-63 Hz |
| High-overload power | 110 kW at 200% 3 s, 150% 57 s, 100% 240 s; ambient temperature -20 to +50 °C (HO) |
| Low-overload power | 132 kW at 150% 3 s, 110% 57 s, 100% 240 s; ambient temperature -20 to +40 °C (LO) |
| Mounting | Push-through |
| Braking chopper | Integrated |
| Protection | IP20 |
| Included equipment | Without Control Unit and operating unit |
| Firmware release | CU Firmware version V4.7 SP6 |
| Lifecycle | Product cancellation |
Key Features
- Power module type: SINAMICS G120 Power Module PM 240-2 spare part with push-through mounting and no filter.
- Supply: 380-480 V 3 AC +10/-20%, 47-63 Hz.
- High-overload power: 110 kW at 200% for 3 s, 150% for 57 s, and 100% for 240 s; ambient temperature -20 to +50 °C (HO).
- Low-overload power: 132 kW at 150% for 3 s, 110% for 57 s, and 100% for 240 s; ambient temperature -20 to +40 °C (LO).
- Braking and protection: Integrated braking chopper; degree of protection IP20.
- Dimensions and exclusions: 754x384x358 (HxWxD); without Control Unit and operating unit. Released as of CU Firmware version V4.7 SP6.
Frequently Asked Questions
1. What power module is the Siemens 6SL3211-1PE32-5UL0?
It is a SINAMICS G120 Power Module PM 240-2 spare part with push-through mounting, no filter, and an integrated braking chopper.
2. What supply does the 6SL3211-1PE32-5UL0 use?
The supply is 380-480 V 3 AC +10/-20% at 47-63 Hz.
3. What are its high-overload and low-overload power ratings?
High overload is 110 kW at 200% for 3 s, 150% for 57 s, and 100% for 240 s at -20 to +50 °C (HO). Low overload is 132 kW at 150% for 3 s, 110% for 57 s, and 100% for 240 s at -20 to +40 °C (LO).
4. What is included with this configuration?
It is without a Control Unit and operating unit.
