Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product type | SINAMICS G120 PM 240-2 push-through power module |
| Supply | 380-480 V 3 AC +10/-20%, 47-63 Hz |
| Integrated filter | Class A |
| Integrated braking function | Braking chopper |
| High overload power | 110 kW at 200% 3 s, 150% 57 s, 100% 240 s |
| High overload ambient temperature | -20 to +50 °C (HO) |
| Low overload power | 132 kW at 150% 3 s, 110% 57 s, 100% 240 s |
| Low overload ambient temperature | -20 to +40 °C (LO) |
| Degree of protection | IP20 |
| Included equipment | Power module only; without Control Unit and operating unit |
| Firmware release condition | Released as of CU firmware version V4.7 SP6 |
Key Features
- Power module type: SINAMICS G120 PM 240-2 push-through power module and spare part.
- Supply: 380-480 V 3 AC +10/-20%, 47-63 Hz.
- Integrated functions: Integrated Class A filter and braking chopper.
- High overload rating: 110 kW at 200% for 3 s, 150% for 57 s, and 100% for 240 s; ambient temperature -20 to +50 °C (HO).
- Low overload rating: 132 kW at 150% for 3 s, 110% for 57 s, and 100% for 240 s; ambient temperature -20 to +40 °C (LO).
- Installation and exclusions: 754x384x358 (HxWxD), FSF, IP20; without Control Unit and operating unit.
Frequently Asked Questions
1. What is the supply for the Siemens 6SL3211-1PE32-5AL0?
The supply is 380-480 V 3 AC +10/-20% at 47-63 Hz.
2. What are the high overload and low overload ratings?
High overload is 110 kW at 200% for 3 s, 150% for 57 s, and 100% for 240 s, with ambient temperature -20 to +50 °C (HO). Low overload is 132 kW at 150% for 3 s, 110% for 57 s, and 100% for 240 s, with ambient temperature -20 to +40 °C (LO).
3. What is included in the configuration?
It is without a Control Unit and operating unit.
4. What are the dimensions and protection degree?
The dimensions are 754x384x358 (HxWxD), with IP20 degree of protection.
