Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Product type | SINAMICS G120 Power Module PM 240-2 |
| Supply | 200-240 V 3AC, +10/-20%, 47-63 Hz |
| High overload power | 15 kW |
| High overload cycle | 200% 3 s, 150% 57 s, 100% 240 s |
| High overload ambient temperature | -20 to +50 °C (HO) |
| Low overload power | 18.5 kW |
| Low overload cycle | 150% 3 s, 110% 57 s, 100% 240 s |
| Low overload ambient temperature | -20 to +40 °C (LO) |
| Degree of protection | IP20 |
| Configuration exclusions | Without Control Unit and operating unit |
Key Features
- Power module type: SINAMICS G120 Power Module PM 240-2, push-through, unfiltered, supplied as a spare part.
- Supply: 200-240 V 3AC, +10/-20%, 47-63 Hz.
- Integrated braking chopper: Integrated braking chopper.
- High overload rating: 15 kW at 200% for 3 s, 150% for 57 s, and 100% for 240 s; ambient temperature -20 to +50 °C (HO).
- Low overload rating: 18.5 kW at 150% for 3 s, 110% for 57 s, and 100% for 240 s; ambient temperature -20 to +40 °C (LO).
- Installation and protection: Push-through dimensions: 517 x 275 x 237 mm (H x W x D). Degree of protection IP20. Control Unit and operating unit are not included.
Frequently Asked Questions
1. What is the exact function and configuration of the 6SL3211-1PC26-8UL0?
It is a spare SINAMICS G120 Power Module PM 240-2, push-through and unfiltered, with an integrated braking chopper.
2. What power ratings are available for this model?
High overload is 15 kW at 200% for 3 s, 150% for 57 s, and 100% for 240 s. Low overload is 18.5 kW at 150% for 3 s, 110% for 57 s, and 100% for 240 s.
3. What is included in the configuration?
It is without Control Unit and operating unit. Verify the required configuration when requesting a quote.
