Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Module type | SINAMICS G120 PM230 power module |
| Supply | 380-480 V 3AC +10/-10% |
| Frequency | 47-63 Hz |
| Low-overload power | 75 kW at 110% for 60 s, 100% for 240 s |
| Low-overload continuous condition | 100% for 240 s |
| Ambient temperature | 0 to +40 °C (LO) |
| Degree of protection | IP20 |
| Released for | CU240B/E-2 and CU230P-2 with firmware version V4.4 or higher |
| Included equipment | Without Control Unit and operating unit |
| Safety | No safety supported |
Key Features
- Power module: SINAMICS G120 PM230 power module spare part with an integrated class A filter.
- Supply and frequency: Supply: 380-480 V 3AC +10/-10%; frequency: 47-63 Hz.
- Low-overload rating: 75 kW at 110% for 60 s and 100% for 240 s, with ambient temperature 0 to +40 °C (LO).
- Protection and dimensions: Degree of protection: IP20. Dimensions HxWxD: 934x 350x 316.
- Configuration exclusions: Without Control Unit and operating unit; no safety is supported.
- Firmware and release: Released for CU240B/E-2 and CU230P-2 with firmware version V4.4 or higher. Product cancellation.
Frequently Asked Questions
1. What supply does the 6SL3210-1NE31-5AL0 power module use?
It uses 380-480 V 3AC +10/-10% at 47-63 Hz.
2. What is the low-overload rating?
The low-overload rating is 75 kW at 110% for 60 s and 100% for 240 s at ambient temperature 0 to +40 °C (LO).
3. What is excluded from this configuration?
It is without Control Unit and operating unit, and no safety is supported.
