Product Overview
Technical Summary
| Parameter | Value |
|---|---|
| Rated power | PN=2kW |
| DC link voltage | UDC=600V |
| Standstill torque | M0=6.4Nm (100K) |
| Rated speed | NN=4500rpm |
| Encoder type | Incremental SIN/COS 1VPP |
| Encoder resolution | 2048 S/R W. C-AND D-SPUR (ENCODER IC2048S/R) |
| Cooling | Naturally cooled |
| Mounting | FRAME SIZE IMB 5 (IM V1, IM V3), FLANGE 1 |
| Power connection | Rotatable POWER CONNECTOR |
| Protection | IP65 DE flange, IP67 |
| Temperature sensor | KTY TEMPERATURESENSOR |
Key Features
- Motor rating: PN=2kW, UDC=600V, M0=6.4Nm (100K) and NN=4500rpm.
- Encoder: Incremental SIN/COS 1VPP encoder; 2048 S/R W. C-AND D-SPUR (ENCODER IC2048S/R).
- Construction and cooling: Naturally cooled motor with FRAME SIZE IMB 5 (IM V1, IM V3) and FLANGE 1.
- Connections and brake: Includes a rotatable POWER CONNECTOR, KTY TEMPERATURESENSOR and holding brake.
- Shaft and tolerance: Shaft with fitted key and tolerance N.
- Protection and lifecycle: Degree of protection: IP65 DE flange and IP67. Product cancellation.
Frequently Asked Questions
1. What motor ratings does Siemens 1FK7061-4CH71-1AB2 have?
It has PN=2kW, UDC=600V, M0=6.4Nm (100K) and NN=4500rpm.
2. Which encoder is fitted to this motor?
It has an incremental SIN/COS 1VPP encoder with 2048 S/R W. C-AND D-SPUR (ENCODER IC2048S/R).
3. How is the motor mounted and cooled?
It is naturally cooled and uses FRAME SIZE IMB 5 (IM V1, IM V3) with FLANGE 1.
4. What connections and protection details should be verified?
The motor has a rotatable POWER CONNECTOR, KTY TEMPERATURESENSOR, holding brake, IP65 DE flange protection and IP67.
